Pay attention to the following points when using the semi-automatic edge banding machine:
1. A problem in the pressing part leads to abnormal operation of the trimming and polishing equipment.
If the plate is not pressed tightly, or there is a height before and after the pressing vertical plate, when the plate travels to the glued part, the rubber coating wheel and the pressing wheel exert a certain pressure on the side of the plate, causing the plate to shift and deviate from the reference line. The subsequent process cannot be completed. To
Solution:Press the plate tightly, and adjust the tightness before and after the adjustment is the same, then put the reference ruler and profiling wheel of the trimming tool against the plate, and finally adjust the tool to the desired effect, and the problem will be solved.
2. No board surface is found for the trimming datum plane.
The edge trimming knife can accurately trim the edge banding strip to the ideal line thanks to the horizontal ruler (oblique pressing wheel or arc bearing plate) and vertical ruler (profiling wheel) next to the trimming knife. If they can't stick to the moving board, it is bound to be unable to repair proper lines.
Solution:Send a long plate with a flat end surface into the edge banding machine (be careful not to apply glue). When the plate travels to a position that can cover polishing, scraping, finishing, and rough repair, stop the conveyor belt and use the plate surface As a benchmark, put the above-mentioned horizontal and vertical reference pieces against the plate, put the cutting edge of the tool close to the edge of the plate, and wait for fine-tuning later until the desired effect appears.
3. Loose screws cause unstable trimming.
Solution: find the benchmark, tighten the screw, adjust the tool
